STRUCTURING 4R-450

Machine for structuring parquet, decks, wall coverings and beams or scratching synthetic wood.

VIDEO

Description

It composed of four groups of structuring, roller pressure and conveyor.

Automatic positioning of the clamps.

Manual positioning rollers

Roller speed control.

Inverter adjustable conveyor.

TECHNICAL DATA:

DIMENSIONS:

Length: 3.250mm
Width:: 1.055

Height: 2.150mm

MACHINE CONTROL: AUTOMATIC AND MANUAL

TRANSPORT SPEED: 1 a 13 m/min

ROLLER n.1 SPEED: 50 a 1000 Rpm

ROLLER n.2 SPEED 50 a 1000 Rpm

VELOCIDAD RODILLO 3: 50 a 1000 Rpm

VELOCIDAD RODILLO 4:

WORKING WIDTH:: 450mm

WORKING HEIGHT:  4 a 120 mm

VOLTAGE: 400 V three phases, neutral and ground.

POWER: 18 kW

WEIGHT:  1.650 Kg

DATA SHEET
